Schneider Electric LC1D32LE7
Schneider Electric TeSys™ D LC1D32LE7 Standard IEC Contactor With Protective Cover, 208/609 VAC, 300 VDC V Coil, 32/50 A, 3NO Contact, 3 Poles
Brand: Schneider Electric
Item ID: 458150
MPN: LC1D32LE7
UPC: 785901292159
Login for Price
Features
- Without built-in bi-directional peak limiting diode suppressor coil technology
- IP2X IEC 60529/VDE 0106
- 50 A at 60 deg C for power circuit and 10 A at 60 deg C for signaling circuit
Description
Schneider Electric TeSys™ D IEC Contactor, Standard, Series: LC1D, 208/609 VAC, 300 VDC Coil, 32/50 A Maximum Load Current, 70 VA Inrush, 7/7.5 VA Hold-In Coil, 3 Pole, 50/60 Hz Frequency, 15 kW Wattage, Non-Reversing Contact, 3NO Contact Configuration, 1 NO-1 NC Auxiliary Contacts, Power Factor: 0.75 Inrush, 0.3 Hold-In, Screw Clamp Connection, Screw Clamp Terminal, IP2X Enclosure, 3600 Cycles/hr Operating Cycles, -4 to 70 deg C Operating, Rail/Surface Mounting, 45 mm W x 92 mm D x 85 mm H Dimensions
Specifications
Coil Power Rating |
70 VA Inrush, 7/7.5 VA Hold-In |
Coil Voltage |
208/609 VAC, 300 VDC |
Connection Type |
Screw Clamp |
Contact Configuration |
3NO |
Contact Type |
Non-Reversing |
Dimensions |
45 mm W x 92 mm D x 85 mm H |
Enclosure Type |
IP2X |
Frequency Rating |
50/60 Hz |
Maximum Load Current |
32/50 A |
Mounting Type |
Rail/Surface |
Number of Auxiliary Contacts |
1 NO-1 NC |
Number of Poles |
3 |
Operating Cycles |
3600 Cycles/hr |
Operating Temperature |
-4 to 70 deg C |
Power Factor |
0.75 Inrush, 0.3 Hold-In |
Series |
LC1D |
Terminal Type |
Screw Clamp |
Type |
Standard |
Wattage |
15 kW |
Standard Approval |
BV/CCC/DNV (Det Norske Veritas)/GL/GOST/LROS/RINA Certification|CE Marked|CSA File No. LR43364|EN 60947-4-1/60947-5-1|File No. E164862 NLDX|IEC 60947-4-1/60947-5-1/60647-4|IEC 60529/VDE 0106|UL 508|RoHS Compliant|PROP65: This product can expose you to chemicals including: Antimony oxide & Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.p65warnings.ca.gov. |
Application |
Motor Control and Resistive Load Application |
