Square D™ MGA36600
Square D™ PowerPact™ MGA36600 Type MGA Molded Case Circuit Breaker, 600 VAC, 600 A, 65 kA at 240 VAC/35 kA at 480 VAC/18 kA at 600 VAC Interrupt, 3 Poles, Electronic Basic ET1.0 Trip
Brand: Square D™
Item ID: 392367
MPN: MGA36600
Login for Price
Description
PowerPact™ M-Frame Molded Case Circuit Breaker, MGA36600 are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPact™ M-frame circuit breakers are available with Micrologic electronic trip units. This breaker is certified to UL, IEC, CE, CSA Standards.
Square D™ PowerPact™ Molded Case Circuit Breaker, Type MGA, 600 VAC, 600 A, 50/60 Hz, 65 kA at 240 VAC/35 kA at 480 VAC/18 kA at 600 VAC Interrupt, M Frame, Electronic Basic ET1.0 Trip, 300 to 800 A Trip, 3 Pole, 3 ph, Electronic Actuator, I-Line™/Load Lug, 3/0 AWG to 500 kcmil Wire, Plug-On Mount, 40 deg C, 8.1 in L x 8.3 in W x 12.8 in H
Specifications
Actuator Type |
Electronic |
Amperage Rating |
600 A |
Connection Type |
I-Line™/Load Lug |
Dimensions |
8.1 in L x 8.3 in W x 12.8 in H |
Frame |
M |
Frequency Rating |
50/60 Hz |
Interrupt Rating |
65 kA at 240 VAC/35 kA at 480 VAC/18 kA at 600 VAC |
Mounting Type |
Plug-On |
Number of Poles |
3 |
Phase |
3 ph |
Temperature Rating |
40 deg C |
Trip Range |
300 to 800 A |
Trip Type |
Electronic Basic ET1.0 |
Type |
Type MGA |
Voltage Rating |
600 VAC |
Wire Size |
3/0 AWG to 500 kcmil |
Standard Approval |
Buy American Act Compliant|RoHS Compliant|CSA Certified|IEC Certified|UL Listed|PROP65: This product can expose you to chemicals including: Lead and Lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65warnings.ca.gov |
Application |
For providing overload and short circuit protection |
Documentation
Catalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_d5e86692853407af06e1db2392a27924bce74a09487bdf003ba66dbf7eacf061.pdf
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_MGP36600_Owners_User_Manual.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_MGP36600_Owners_User_Manual.pdf
Owners/User Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_PJL36080U44A_User_Manual.pdf
RoHS https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_MGA36600_RoHS.pdf
Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_c4c63fc20ef2135416041306cf202f255ca6074d4251036883c3cde9f1ab2953.pdf
