Square D™ MGL36400
Square D™ PowerPact™ MGL36400 Type MGL Molded Case Circuit Breaker, 600 VAC/250 VDC, 400 A, 65 kA at 240 VAC/35 kA at 480 VAC/18 kA at 600 VAC Interrupt, 3 Poles, Electronic Basic ET1.0 Trip
Brand: Square D™
Item ID: 387880
MPN: MGL36400
Login for Price
Description
PowerPact™ M-Frame Molded Case Circuit Breaker, MGL36400 are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPact™ M-frame circuit breakers are available with Micrologic electronic trip units. This breaker is certified to UL, IEC, CE, CSA Standards.
Square D™ PowerPact™ Molded Case Circuit Breaker, Type MGL, 600 VAC/250 VDC, 400 A, 50/60 Hz, 65 kA at 240 VAC/35 kA at 480 VAC/18 kA at 600 VAC Interrupt, M Frame, Electronic Basic ET1.0 Trip, 300 to 800 A Trip, 3 Pole, 3 ph, Electronic Actuator, Lug, 3/0 AWG to 500 kcmil Wire, 40 deg C, 8.1 in L x 8.3 in W x 12.8 in H
Specifications
Actuator Type |
Electronic |
Amperage Rating |
400 A |
Connection Type |
Lug |
Dimensions |
8.1 in L x 8.3 in W x 12.8 in H |
Frame |
M |
Frequency Rating |
50/60 Hz |
Interrupt Rating |
65 kA at 240 VAC/35 kA at 480 VAC/18 kA at 600 VAC |
Number of Poles |
3 |
Phase |
3 ph |
Temperature Rating |
40 deg C |
Trip Range |
300 to 800 A |
Trip Type |
Electronic Basic ET1.0 |
Type |
Type MGL |
Voltage Rating |
600 VAC/250 VDC |
Wire Size |
3/0 AWG to 500 kcmil |
Standard Approval |
Buy American Act Compliant|RoHS Compliant|CSA Certified|IEC Certified|UL Listed|PROP65: Cancer and Reproductive harm - www.P65warnings.ca.gov |
Application |
For providing overload and short circuit protection |
