Square D™ P1200R
Square D™ P1200R A01 Enclosure, 533.4 mm W x 247.65 mm D x 1323.98 mm H, NEMA 3R Rating, Steel
Brand: Square D™
Item ID: 527330
MPN: P1200R
UPC: 785901474937
Login for Price
Features
- For use with type PGL/PJL/PKL/PLL 2/3 pole 600 to 1200 a circuit breaker
Description
All enclosures will accept 80% rated circuit breakers. The P1200 enclosures will accept 100% rated circuit breakers to 800 A. If a CT neutral is required, the enclosure will no longer accept a 200% neutral. The M800R and the P1200R enclosures have a blank top end wall and require field cut openings.
Square D™ Enclosure, Series: A01, 533.4 mm Width, 247.65 mm Depth, 1323.98 mm Height, NEMA 3R Rating, P Frame, 2/3 Pole, 600 to 1200 A Electrical Rating, Surface Mounting, Steel
Specifications
Depth |
247.65 mm |
Electrical Ratings |
600 to 1200 A |
Frame |
P |
Height |
1323.98 mm |
Material |
Steel |
Mounting Type |
Surface |
NEMA Rating |
NEMA 3R |
Number of Poles |
2/3 |
Series |
A01 |
Width |
533.4 mm |
Standard Approval |
RoHS Compliant|ECCN: EAR99|CSA Certified|REACH Compliant|UL Listed|PROP65: This product can expose you to chemicals including: Antimony oxide and Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov |
Documentation
Catalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_b2691c7338b24a2c72e4540cca7b06b4d4a0e3f235f3ac1cb4546d544de885bb.pdf
Instruction/Installation Manual https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_afaaaf725725ad30daf7c0cb80f63c3b7d162315668975f34399439163a546ed.pdf
RoHS https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_P1200R_RoHS.pdf
Specification Sheet 2 https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/IDW_DOCUMENT_c6651a8a956e44df66f2c33c1b0f611afccb00ce1b52e7ac52b34cb8b7341379.pdf
Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Square_D_P1200R_Specification_Sheet.pdf
