Southwire - Topaz 562
Southwire - Topaz 562 1-Hole Snap-On Conduit Strap, 3/4 in, For Use With Rigid/IMC Conduit, Malleable Iron, Zinc Plated
Brand: Southwire - Topaz
Item ID: 386647
MPN: 562
Login for Price
Features
- Inverted rib for strength
- Use to secure rigid or IMC conduit to wood, masonry or similar surfaces where greater load bearing is required
- To be used with clamp back
Description
Topaz's one hole rigid straps are dependably strong and built to last, manufactured to reliably support Rigid conduit, EMT and IMC to mounting surfaces. Crafted from zinc plated malleable iron.
Southwire - Topaz Conduit Strap, 1-Hole Snap-On, 3/4 in, For Use With: Rigid/IMC Conduit, Malleable Iron, Zinc Plated, 2.56 in L x 0.75 in W x 1.22 in H
Specifications
Dimensions |
2.56 in L x 0.75 in W x 1.22 in H |
Finish |
Zinc Plated |
Material |
Malleable Iron |
Size |
3/4 in |
Suitable For Use With |
Rigid/IMC Conduit |
Type |
1-Hole Snap-On |
Standard Approval |
UL E174011|514B|US Federal Specification No. A-A-50553|NEMA/ANSI FB-1|Federal Specification No. W-F-406D|W-F-406E|W-F-408D|W-S-610D |
Application |
Indoor/Outdoor Applications |
Documentation
Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Topaz_561_Data_Sheet.pdf
