Southwire® 9046SW8808
Southwire® 9046SW8808 Extension Cord, 50 A at 125/250 VAC, 6 ft L Cord, 2 Conductors
Brand: Southwire®
Item ID: 334539
MPN: 9046SW8808
Login for Price
Features
- 6/2 and 8/1 SRDT, 125/250V 50A range power supply cord kit with flanged spade terminals and metal strain relief
- SRDT, round jacketed, black cable
- (2) 6 AWG bare copper
- Metal, included but not attached strain relief
- PVC, black plug material
- 1/4 in flanged spade terminal
- 90 deg inlet male plug
- 3.167 lb weight
- PVC core
Description
Southwire® Extension Cord, 50 A at 125/250 VAC, 6 ft Cord, 2 Conductors, 6 AWG Conductor, Copper, 0.8 in Outside Dia, PVC Insulation, PVC, NEMA 14-50R Receptacle, NEMA 14-50P Plug, -20 to 60 deg C, Black
Specifications
Color |
Black |
Conductor Material |
Copper |
Conductor Size |
6 AWG |
Cord Length |
6 ft |
Electrical Ratings |
50 A at 125/250 VAC |
Insulation Material |
PVC |
Jacket Material |
PVC |
Number of Conductors |
2 |
Outside Diameter |
0.8 in |
Plug Type |
NEMA 14-50P |
Receptacle Type |
NEMA 14-50R |
Temperature Rating |
-20 to 60 deg C |
Standard Approval |
RoHS Compliant|UL 817|PROP65: This product contains material that, the State of California has determined, may cause cancer or reproductive harm. www.P65PROP65s.ca.gov/product |
Documentation
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Southwire_3488SW0002_Specification_Sheet.pdf https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Southwire_3488SW0002_Specification_Sheet.pdf
