WIRE 10 THHN STRANDED BLACK - 2500FT REEL
10 THHN Stranded Black - 2500ft Reel: Reliable, heat-resistant wire ideal for conduit and building wiring.
Brand: WIRE
Item ID: 330717
MPN: 10 THHN STRANDED BLACK - 2500FT REEL
Login for Price
Features
- Color code polyvinyl chloride, heat and moisture resistant, flame retardant compound
- Stranded, uncoated bare copper per ASTM-B3, ASTM-B8 and ASTM-B787
- A tough, polyamide, nylon outer covering per UL-83 and UL-1063
- Suitable for wet, damp and dry locations
- Rated gasoline and oil-resistant
Description
Building Wire, Type THHN, Reel Packaging, 600 VAC, 40 A, 1 Conductor, Stranded Copper Conductor, 10 AWG Conductor, 0.161 in OD, 2500 ft Length, 19 Strands, PVC Insulation, Nylon Jacket, Black Jacket, 90 deg C
Specifications
Amperage Rating |
40 A |
Conductor Size |
10 AWG |
Conductor Type |
Stranded Copper |
Insulation Material |
PVC |
Jacket Color |
Black |
Jacket Material |
Nylon |
Length |
2500 ft |
Number of Conductors |
1 |
Outside Diameter |
0.161 in |
Packaging Type |
Reel |
Strands |
19 |
Temperature Rating |
90 deg C |
Type |
Type THHN |
Voltage Rating |
600 VAC |
Standard Approval |
ASTM Class B3/B8/B787|AWM Spec 1316/1317/1318/1319/1320/1321|Buy American Act Compliant|RoHS Compliant|REACH Compliant|UL File E-123774/E-156878/E-156879|cUL Listed|MasterSpec Division 26 Sections 260519/260523|CSA C22.2 #75|ARRA 2009 Section 1605|UL-83/1063/1581/2556|Federal Specification A-A-59544 |
Application |
Commercial, General Purpose, New Construction and Rewiring for 600 V Applications |
