WIRE 4 THHN ALUMINUM BLACK
4 THHN Aluminum Black: High-quality, heat-resistant wire for reliable conduit and raceway installations.
Brand: WIRE
Item ID: 466399
MPN: 4 THHN ALUMINUM BLACK
Login for Price
Features
- Sunlight-resistant in all colors (sizes 6 AWG and larger)
- Rated gasoline and oil-resistant
Description
Type THHN/THWN-2 building wire is intended for general purpose applications as defined by the National Electrical Code® (NEC®). Type THHN-THWN-2 is permitted for new construction or rewiring for 600 V applications.
Building Wire, Type THWN-2, Series: AA-8000, Reel Packaging, 600 VAC, 75 A, 1 Conductor, Stranded Aluminum Conductor, 4 AWG Conductor, 0.305 in OD, 1000 ft Length, 7 Strands, PVC Insulation, Nylon Jacket, Black Jacket, 90 deg C
Specifications
Amperage Rating |
75 A |
Conductor Size |
4 AWG |
Conductor Type |
Stranded Aluminum |
Insulation Material |
PVC |
Jacket Color |
Black |
Jacket Material |
Nylon |
Length |
1000 ft |
Number of Conductors |
1 |
Outside Diameter |
0.305 in |
Packaging Type |
Reel |
Series |
AA-8000 |
Strands |
7 |
Temperature Rating |
90 deg C |
Type |
Type THWN-2 |
Voltage Rating |
600 VAC |
Standard Approval |
Buy American Act Compliant|RoHS Compliant|UL-83/UL-758/UL-1063/UL-1581/UL-2556/UL E-156879|ASTM B800/ASTM B801/ASTM B836|Federal Specification AA-59544|CSA C22.2 No. 75|NEMA WC70/ICEA S-95-658|ANSI NFPA 79 AWM|New York State DOS-16120-87-1222-1048|IEEE 1202/FT4|ICEA T-29-520|ARRA 2009 Section 1605|MasterSpec Division 26 Sections 260519, 260523 |
Application |
Commercial Applications |
