Transformer Selection Guide for Electrical Contractors

Last updated:August 7, 2026

TL;DR

Select a transformer from verified load data, primary and secondary voltage, phase, wiring configuration, kVA, impedance, environment, enclosure, harmonics and available fault current. Plan overcurrent protection, secondary conductors, grounding, bonding, ventilation and working space before ordering. Use taps onlyas the manufacturer permits, and do not treat a K-factor rating as a cure forharmonic distortion.

Transformer selection affects far more than voltage. An incorrect unit can createcapacity problems, excessive voltage drop, coordination issues, overheating,objectionable sound or grounding complications.

Contractors should confirm the complete electrical design before placing an order.Product availability matters, but a transformer that arrives quickly is of little use if its voltage, winding configuration, impedance or enclosure does not matchthe project.

What does a transformer do?

A transformer transfers alternating-current electrical energy between windingsthrough electromagnetic induction. Depending on its design and connection, it can step voltage up or down and may provide electrical isolation between its primaryand secondary circuits.

An autotransformer uses a common winding shared by the input and output. It can be smaller than a comparable isolation transformer, but it does not provide electrical isolation between the two circuits.

Common transformer types

Transformer type	What it does	Selection concerns
Dry-type distribution	Supplies panels and equipment at a different utilization voltage without liquid insulation.	kVA, voltage, phase, winding configuration, impedance, temperature rise, sound, ventilation and enclosure.
Liquid-immersed	Uses an insulating liquid for insulation and heat transfer.	Location, fluid type, fire protection, containment, vault or pad requirements,maintenance and environmental exposure.
Buck-boost	Provides a comparatively small voltage correction, commonly through anautotransformer connection.	Exact source voltage, required output, load current, phase, connection diagram and lack of isolation.
Control transformer	Supplies control circuits, contactors, relays and similar loads.	Inrush, control-circuit VA, voltage regulation, protection and equipment listing.
Mini power center	Combines a transformer with panelboard and protective components in oneassembly.	Assembly ratings, available fault current, feeder requirements, enclosure, space and manufacturer options.

Browse electrical transformers

Transformer nameplate information that matters

kVA rating

Kilovolt-amperes describe the transformer's apparent-power rating. Selection starts with calculated load data, not the rating of the upstream breaker or an estimate based solely on panel size.

Motor starting, nonlinear loads, duty cycle, continuous-load requirements and expected expansion may affect the design. Diversity or demand factors should be applied only when permitted and supported by the project calculations.

Primary and secondary voltage

Confirm both nominal voltages and the actual system configuration. “208 volts” does not identify whether the system is single-phase or three-phase, grounded or ungrounded, or whether a neutral is required.

A designation such as 208Y/120 identifies a grounded-wye secondary with 208 voltsphase-to-phase and 120 volts phase-to-neutral. The connected loads and distributionsystem must match that configuration.

Phase and winding configuration

Verify single-phase or three-phase service along with delta, wye or other winding configurations. Winding configuration affects grounding, neutral availability, phase shift, fault behavior and downstream equipment compatibility.

Impedance

Transformer impedance affects voltage regulation and the amount of fault current available on the secondary. A lower impedance can produce higher available secondaryfault current.

Use manufacturer data and the project short-circuit analysis when verifying equipment interrupting and short-circuit ratings. Do not estimate available fault current fromkVA alone.

Temperature rise and insulation system

Temperature-rise ratings describe transformer heating under specified conditions. A lower-rise design may operate cooler under comparable conditions, but it does not automatically guarantee better efficiency, lower sound or longer life.

Compare actual manufacturer loss, temperature, sound and loading data rather than relying on the temperature-rise number by itself.

K-factor

A K-rated transformer is designed to tolerate additional heating associated with specified nonlinear loads. It does not remove harmonic current or correct voltage distortion.

LED drivers, computers and variable-frequency drives do not automatically require a K-13 transformer. Review the load spectrum, neutral loading, equipment design and project specifications. A harmonic study or engineer's review may be necessary.

Enclosure and environmental rating

Match the complete enclosure rating to the location. Indoor dust, rain, hose-directedwater, corrosion and coastal exposure are different conditions. Do not select an enclosure solely from a shorthand description such as “outdoor” or “weatherproof.”

Taps

Some transformers include primary-voltage taps to accommodate variations in the supplied voltage. Tap ranges and increments vary by model.

Unless the equipment is specifically designed for energized tap changing, establish an electrically safe work condition before changing a tap. Follow the nameplate,wiring diagram and manufacturer instructions.

Transformer selection checklist

Confirm the project-approved kVA or load requirement.
Verify primary voltage, secondary voltage and frequency.
Confirm phase and winding configuration.
Confirm whether a neutral is required.
Identify motor starting and other significant inrush loads.
Identify nonlinear loads and documented harmonic requirements.
Confirm specified impedance and available-fault-current requirements.
Confirm the approved primary and secondary protection requirements.
Confirm the approved grounding and bonding requirements.
Match the enclosure to the installation environment.
Verify ventilation, access, working-space and sound requirements.
Review applicable federal efficiency requirements.
Confirm accessories, dimensions, weight and mounting method.
Verify lead time and branch availability before issuing the purchase order.

Protection, conductors, grounding and bonding

Transformer protection, secondary-conductor protection, grounding and bonding are project design decisions, not product-selection shortcuts. Requirements depend on the transformer, system configuration, conductor arrangement, load, available fault current, equipment ratings and applicable code provisions.

Use the approved project design, manufacturer instructions and the applicable requirements of NFPA 70 when these details are established. If field conditions or project documents are unclear, resolve them with the responsible qualified professional and the Authority Having Jurisdiction before ordering, modifying or energizing equipment.

Electrical safety during service and commissioning

Transformer testing, commissioning and service can expose workers to hazardous voltage, stored energy, high fault current and arc-flash hazards. Follow the employer's electrical safety program, applicable lockout/tagout procedures and manufacturer instructions.

Only qualified personnel should test, commission, troubleshoot or service transformer equipment.

Location, ventilation and sound

Ventilation

Ventilated dry-type transformers depend on airflow. Keep marked ventilation openingsclear and maintain the manufacturer's required distances from walls and otherequipment.

Do not install a transformer in a closet, ceiling space or restricted enclosureunless the product and installation are permitted for that location.

Access and working space

Plan access, mounting and required working space before equipment is delivered.Transformer dimensions shown on a submittal do not include conductor bending space,ventilation clearance, access for terminations or every working-space requirement.

Sound and vibration

All energized transformers produce some sound. Avoid locating them against wallsshared with offices, classrooms, residential rooms or other sound-sensitive spaceswhen practical.

Follow the manufacturer’s mounting instructions. Approved isolation pads or flexibleconnections may reduce transmitted vibration when correctly selected and permitted.

Efficiency requirements

Federal efficiency requirements for covered distribution transformers appear in10 CFR Part 431, Subpart K. The rule applies only to equipment within its definedscope and contains exclusions for several specialized transformer types.

The Department of Energy adopted amended efficiency standards in 2024. Compliancewith the amended levels is required for covered transformers manufactured on orafter April 23, 2029. Until then, the current applicable tables remain in effect.

Verify the manufacturing date, model certification and project specifications ratherthan describing a unit only as “DOE compliant.”

Pre-energization and closeout

Testing and startup should follow the manufacturer’s instructions, projectcommissioning plan and employer safety program. A basic documentation package mayinclude:

Approved submittal and wiring diagram
Nameplate photograph
Transformer location and equipment identification
Primary and secondary voltage
Phase and winding configuration
Final deenergized tap position
Grounding and bonding documentation
Torque records where required
Secondary-conductor protection method
Protective-device information and settings
Manufacturer test and maintenance instructions

Do not perform insulation-resistance, high-potential or other specialized testingunless the manufacturer and commissioning procedure permit it. Connected electronics,surge devices or monitoring equipment may need to be isolated before testing.

Conditions that require investigation

Overheating, unexpected secondary voltage, repeated protective-device operation or excessive sound can indicate a system, installation, loading or equipment problem. These symptoms should be evaluated by qualified personnel using the manufacturer’s documentation, approved project information and appropriate test procedures.

Do not change taps, protective-device ratings or settings, grounding connections, internal hardware or conductor arrangements solely to make a symptom disappear. Identify and correct the underlying cause using an approved procedure.

When to involve the engineer or AHJ

The secondary-conductor layout does not clearly fit a permitted method.
The grounding or winding configuration is unusual.
Available fault current or equipment ratings are uncertain.
Transformers will be paralleled.
The installation involves healthcare, hazardous locations or life-safety systems.
A liquid-immersed transformer is proposed indoors or near a building.
A vault, rooftop support or outdoor pad must be designed.
The load contains substantial nonlinear or regenerative equipment.
The transformer interfaces with generation, energy storage or another source.
Utility service data or short-circuit information is incomplete.

Code note for Long Island contractors

New York's 2025 Uniform Code became fully effective on December 31, 2025. The 2025 Building Code of New York State requires applicable electrical systems to comply with its provisions and NFPA 70.

Confirm the permit date, applicable code requirements, utility requirements, project specifications and direction from the Authority Having Jurisdiction before ordering equipment or beginning installation.

Frequently asked questions

What information is needed to order a transformer?

At minimum, provide kVA, frequency, phase, primary voltage, secondary voltage,winding configuration, enclosure, temperature-rise requirement, impedance orfault-current requirements, taps, harmonic requirements, mounting method andaccessories.

What is the difference between an isolation transformer and an autotransformer?

An isolation transformer has separate primary and secondary windings. Anautotransformer shares a winding between the input and output and does not provideelectrical isolation.

Do LED and computer loads always require a K-rated transformer?

No. Review the actual harmonic content, neutral loading, transformer design and project requirements. A K-rated transformer tolerates specified harmonic heatingbut does not correct harmonic distortion.

Can a 208Y/120-volt transformer serve a 240-volt load?

Not directly at 240 volts. A 208Y/120-volt secondary provides 208 voltsphase-to-phase and 120 volts phase-to-neutral. The load needs a source rated forits required input voltage or another approved voltage-correction solution.

Can two transformers be connected in parallel?

Parallel operation requires an engineered design and manufacturer approval.Voltage ratio, polarity, phase sequence, phase displacement, impedance, taps,ratings and conductor arrangements must be compatible.

Who should determine transformer grounding and bonding requirements?

Grounding and bonding requirements should come from the approved project design and applicable code requirements. Where the system configuration or field conditions are unclear, the responsible qualified professional and AHJ should resolve them before installation or modification.

Can transformer taps be used to correct a voltage problem?

Use taps only within the manufacturer’s permitted configurations and the approved project requirements. A tap change should not be used as a substitute for diagnosing overload, conductor voltage drop, incorrect source voltage or another unresolved system condition.

Need help sourcing a transformer?

Revco supplies dry-type, buck-boost, control, low-voltage and other transformer products for Long Island contractors. Product selection, availability and lead time vary by model and branch.

Browse electrical transformers

You can alsorequest a transformer quotewith the project-approved transformer requirements.

For an urgent requirement,contact your nearest Revco branchwith the complete transformer nameplate or specification.

Safety and code disclaimer:This article provides general product selection information for qualified professionals. It is not a substitute for load calculations, short-circuit and coordination studies, engineering, NFPA 70, workplace safety procedures, manufacturer instructions, utility requirements or direction fromthe applicable Authority Having Jurisdiction.
